106C_ANMBAntimicrobial 106C Gravity Hinge - Concealed Fix

Specification

Material Diecast Zinc, Alloy ZP3
#304 Stainless Steel Shaft
Nylon Inserts, ABS Snap On Covers
Finish Antimicrobial Coated
Mounting Concealed Screw Fix or Bolt Through
Specify 106C_LHHC_ANMB: Left Hand, Hold Closed. Assists door to move towards Hold Closed position
106C_LHHO_ANMB: Left Hand, Hold Open. Assists door to move towards Hold Open position
Features Gravity assisted door opening with lift off capability.
Load Rating 15Kg per hinge
  For optimum performance -
2 hinges per door up to 30Kgs
For doors over 30Kg allow for 15Kg per hinge
Note For Bolt Through use 106C_FACEPLATE Concealed Fix Face Plate (Available in Satin Chrome Plate, Bright Chrome Plate and Satin Nickel Plate)
Disclaimer Gravity hinges contain no mechanical components. Functionality of these hinges can vary depending on the environment.
When selecting this product, please view our Product Disclosure Statement in the Care and Maintenance Download below.
